Neutrik Speakon male (NL4FX)

Gender female

Contact resistance < 2 mΩ (inner) (after lifetime)

Dielectric strength 4 kVdc (peak)

Insulation resistance > 1 GΩ (after dampheat)

Rated current per contact 40 A rms continuous

Rated current per contact 50 A audiosignal, duty cycle 50 %

Rated voltage 250 V (Insulation)

Attention speakON is NOT to be used as an AC mains or power supply connector!

Cable O.D. 7 – 14.5 mm

Cable retention ≥ 220 N (subject to cable O.D. and material)

Lifetime > 5000 mating cycles

Wiresize 4 mm² / 6 mm² (screw type terminals/soldering)

Wiresize 12 AWG / 10 AWG

Wiring screw type terminals or soldering

Locking device Quick Lock (latch)

Contact plating 4 µm Ag

Contacts Brass (CuZn39Pb3)

Insert PBTP 20 % GR

Locking element Zinc diecast (ZnAl4Cu1)

Shell PBTP 20 % GR

Strain relief Polyacetal (POM)

Flammability UL 94 HB

Solderability Complies with IEC 68-2-20

Temperature range -30 °C to +80 °C
